Echo HCA-2620ES-HD - Specifications

31
Specifications
Specifications
These specifications are subject to change without notice.
HCA-2620ES-HD
External dimensions: Length x Width x Height mm 2440 × 273 × 260
Masses:
Unit with specified cutting attachment, empty tank kg 6.5
Unit with specified cutting attachment, full tank kg 7.0
Volume: Fuel tank mL 600
Fuel: Regular grade petrol. Minimum 89 Octane unleaded
petrol is recommended. Do not use fuel containing
methyl alcohol or more than 10% of ethyl alcohol.
Oil Two stroke, air-cooled engine oil. ISO-L-EGD Stand-
ard (ISO/CD 13738), JASO FC/FD grade and ECHO
recommended oil.
Mixing ratio 50: 1 part (2%)
Cutting attachment:
Type Dual action, double sided blade
Cutting length mm 536
Pitch mm 35
Height mm 21
Gear ratio and lubrication: 4.60 reduction and good quality lithium grease
Engine:
Type Air-cooled two stroke, single cylinder
Carburettor Diaphragm type
Magneto Flywheel magneto: CDI system
Spark Plug NGK CMR7H
Starter Recoil starter
Power transmission Automatic Centrifugal clutch
Engine displacement cm³ 25.4
Maximum shaft brake power (ISO 8893) kW 1.0
Fuel consumption at maximum engine power L/h 0.61
Recommended maximum engine speed (With STD at-
tachment installed)
r/min 11500
Recommended engine idling speed r/min 3000
Vibration levels: (ISO 10517) a
hv,eq
Front handle / Rear handle m/s² 7.6 / 7.2
Uncertainty: K m/s² 5.0
Sound pressure level: (ISO 10517) L
pAd
(=L
pAeq
+K
pA
)dB (A)96.6
Uncertainty: K
pA
dB (A) 2.5
Sound power level: (ISO 10517) L
WAd
(=L
WAeq
+K
WA
) dB (A) 109.0
Uncertainty: K
WA
dB (A) 2.5
