PAS-225/SB/VP/VPB SPECIFICATIONS
X7732274006 59
© 09/21 ECHO Incorporated
Shoulder Harness Optional
Idle Speed 3,000 RPM
Clutch Engagement Speed 3,850 RPM
Wide Open Throttle Speed
(W.O.T.)
10,000 RPM
MODEL Curved Shaft Edger
Shaft Length 790 mm (31.1 in.)
Attachment Width 235 mm (9.25 in.)
Attachment Height 290 mm (11.42 in.)
Weight with blade 2.35 kg (5.17 lb.)
Drive Shaft Type 6.35 mm (0.25 in.) Flex Shaft
Rotating Direction Clockwise; viewed from right side
Blade Length 197 mm (7.75 in.)
Gear Case Ratio (unit with
metal blade shield)
2.07:1
Gear Case Ratio (unit with
plastic blade shield)
1.62:1
Shield Open, anti-clog
MODEL Speed-Feed
®
Trimmer
Shaft Length 834 mm (32.8 in.)
Attachment Width 177 mm (6.9 in.)
Attachment Height 236 mm (9.29 in.)
Weight (dry) with line head 1.07 kg (2.3 lb.)
Drive Shaft 6.35 mm (0.25 in.) Flex Shaft
Gear Case Ratio 1.62:1
Direction of Rotation Counter clockwise viewed from the top
Cutter Head
Speed-Feed
®
Nylon line head
Line Capacity 6 m (20 ft.)
MODEL Power Blower
Length 635 mm (25.01 in.)
Width 231 mm (9.10 in.)
Height 212 mm (8.35 in.)
Weight 1.80 kg (3.96 lb.)
Flexible Drive Shaft 6.35 mm (1/4 in.) Flex Shaft
Maximum Air Speed (MPH) 129 - 142 mph *
Maximum Air Volume
347 - 383 ft
3
/min. *
Sound Level at 50 ft. dB(A) scale per
ANSI B175.2
71 dB(A)
* Specifications are for a variety of power heads. Individual unit performance may vary.
MODEL PAS-225 SB
