SERVICE INFORMATION
PB-2100
PB-2155
PB-2200SI
2
1 SERVICE INFORMATION
1-1 Specifications
Model PB-2100 PB-2155 PB-2200SI
Dimensions Length* mm(in) 220 (8.7) 250 (9.8)
Width mm(in) 330 (13.0)
Height mm(in) 340 (13.4)
Dry weight** kg(lb) 4.0 (8.8) 4.1 (9.0) 4.3 (9.5)
Engine Type KIORITZ, air-cooled, two-stroke, single cylinder
Rotation Anticlockwise as viewed from the output end
Displacement cm
3
(in
3
) 21.2 (1.294)
Bore mm(in) 32.2 (1.268)
Stroke mm(in) 26.0 (1.024)
Compression ratio 7.0
Carburettor Type Diaphragm horizontal-draught with primer (purge bulb)
Model ZAMA C1U-K42B ZAMA C1U-K43B
Venturi size-Throttle bore mm(in) 8 - 14 (0.315 - 0.551) 7 - 14 (0.276 - 0.551)
Ignition Type CDI (Capacitor discharge ignition) system
Spark plug RCJ-7Y
Starter Type Automatic rewind - start
Rope diameter x length mm(in) 3.0 x 1000 (0.12 x 39.4) 3.0 x 920 (0.12 x 36.2)
Fuel Type Premixed two-stroke fuel
Mixture ratio 50 : 1 (2 %)
Petrol Minimum 89 octane petrol (RON)
Two-stroke air cooled engine oil ISO-L-EGD (ISO/CD13738), JASO FC
Tank capacity L (U.S.fl.oz.) 0.5 (16.9)
Handle Type Rear Grip
Blower Fan type
Sirocco, single stage
Centrifugal, single stage
Max. air volume (with pipes)
m
3
/min (ft
3
/min) 8.7 (264.9)**
Max. air velocity (with pipes)
m/s (mph) 61 (136)**
Blower pipe length mm (in) Straight 425 (16.73)
mm (in) Fan head nozzle 420 (16.54)
Blower nozzle size, (inner) mm (in) 117 x 26 (4.6 x 1.02) oval shape
Fan head nozzle Standard
Vacuum Shredding knife - - - without - - -
Vacuum pipe ID x L mm(in) - - -
110 x 880 (4.33 x 34.65)
- - -
Dust bag capacity liter(ft
3
) - - - 60 (2.1) - - -
* Without blower pipes
** With fan head nozzle
