SERVICE INFORMATION
PB-46LN PB-46HT
1 SERVICE
INFORMATION
1-1
Specifications
Models PB-46LN
I
PB-46HT
PB-60HT
Dimensions Length* mm(in) 320 (12.6) 320
(
12.6
)
Width*
mm(in) 460 (18.1)
460(
18.1
)
Height* mm(in) 450 (17.7) 450
(
17.7
)
Dry weight without pipes kg(lb) 12.0 (26.4)
I
10.2 (22.4) 10.2
(
22.5
)
Engine Type
KIORITZ, air-cooled, two-stroke, single
cylinder
Rotation Counterclockwise as viewed from the output
end
Displacement
cm3(in3)
44.0 (2.684)) 58.2
(3.550)
Bore mm(in)
40.0 (1.575) 46.0
(
1.811
)
Stroke mm(in)
35.0 (1.378) 35.0
(
1.378
)
Compression
ratio 7.0
6.4
Carburetor Type Diaphragm,
horizontal-draught,
with
primer
Model
ZamaC1M
Ignition Type CDI (Capacitor discharge ignition)
system
in a single integrated
piece
Spark plug BPM7Y,
BPMR7A
Starter Type
Automatic
rewind
Rope diameter x length mm(in) 3.8
X
1400 (0.15
X
55.1)
Fuel Type Premixed two-stroke fuel (Refer to Operator's manual.
)
Tank capacity liter (US.fl.oz.) 1900
(64.2)
Blower Fan type Centrifugal, single
stage
Max. air volume (with
pipes)
m3fmin(ft3fmin) 10.3 (364) 11.5
(406)
Max. air velocity (with
pipes)
m/s(mph) 78.9 (176) 88 (197)
Discharge pipe ID mm(in)
58 (2 1/4} 58 (2 1/4)
*Without blower
pipes.
ID: Inner
diameter
