Echo PB-46LN Service Data

4
SERVICE INFORMATION
PB-46LN PB-46HT
PB-60HT
1-3 Torque limits
Descriptions
Size
kgfecm
in•lbf
Crankcase
M 5
30-40
25-35
Cylinder
M 5
75-85
65-75
Cylinder cover
M 5
30-40
25-35
Intake insulator
M 5
50-60
45-55
Carburetor
M 5
30-40
25-35
Intake adapter clamp
M 5
6-8
5-7
Fan
M 5
75-85
65-75
Fan case
M 5**
30-35
25-30
Flywheel
M10 280-320
245-280
Ignition coil (CDI module)
M 5
30-40
25-35
Dust cover
M 5
10- 15
9- 13
Spark plug
M14
150- 170
130-150
Engine mount
M 5
30-40
25-35
Pawl carrier
M 8
80- 100
70-90
Starter drum (Reel}
M 5*
27-32
23-28
Muffler
M 6
130- 150
110- 130
Muffler bracket
M 5
30-40
25-35
Muffler insulator
M 5
15-20
13- 17
Bracket (Cable/Pipe holder)
M 5
15-20
13- 17
Throttle control (Lever)
M 6
20-30 17-25
Top handle
M 5
15-20
13- 17
Cushion
Fan case side
M 5**
30-35
25-30
Frame side
M 5
30-40
25-35
Regular bolt, nut,
and screw
M 3
6-9
5-8
M 4
13- 18
11
- 16
M 5
27-32
23-28
M 6
45-65
40-55
M 8
110- 150
115- 130
• Apply thread locking sealant (Loctite #222, ThreeBond #1342, or equivalent).
••
Tapping screw.
1-4 Special repairing materials
Material
Location
Remarks
Grease
Rewind spring
Lithium based grease
Starter center post
Oil seal inner lips
Thread locking sealant
Starter drum
Loctite #222, ThreeBond #1342 or equivalent

Echo PB-46LN Specifications

General

Brand	Echo
Model	PB-46LN
Category	Blower
Language	English
