POWER EDGER
OPERATOR'S MANUAL
7
DESCRIPTION
The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions,
power head and other assembly may be necessary.
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts.
Use the contents list to check for missing parts.
CONTENTS
__ 1, Edger Drive Shaft Assembly
__ 1, Power Head
__ 1, Plastic Bag (Co-Pack)
__ 1,Operator's Manual
__ 1,Safety Manual
__ 1,Warranty Registration Card
__ 1, ECHO Emissions and Warranty Statement
__ 1, Echo Power Blend
TM
2-stroke oil sample
__ 1, Front Handle
__ 2, 5x40 mm screws
__ 2, 5 mm nuts
__ 2, Washer, 5
__ 1, Scrench (Combination Spark Plug Socket/Screwdriver)
__ 2, Split pins
__ 1, Locking Tool
__ 1, 8x10 mm Spanner Wrench
__ Safety Glasses
1
2
3
4
5
6
7
8
9
10
11
12
13
16
17
18
19
14
20
15
