Echo PE-200

POWER EDGER
OPERATOR'S MANUAL
9
SPECIFICATIONS
MODEL -----------------------------------------------------PE-200
Length-------------------------------------------------------1750 mm (68.9 in.)
Width-------------------------------------------------------- 300 mm (11.8 in.)
Height ------------------------------------------------------- 290 mm (11.4 in.)
Weight (dry w/cutter head) ------------------------------- 5.38 kg (11.9 lb.)
Engine Type ------------------------------------------------Air cooled, two-stroke, single cylinder gasoline engine
Bore ----------------------------------------------------------32.2 mm (1.27 in.)
Stroke-------------------------------------------------------- 26.0 mm (1.02 in.)
Displacement ----------------------------------------------- 21.2 cc (1.29 cu. in.)
Exhaust ------------------------------------------------------Spark Arrestor Muffler
Carburetor -------------------------------------------------- Zama diaphragm model RB w/purge
Ignition System -------------------------------------------- CDI (capacitor discharge ignition)
Spark Plug -------------------------------------------------- NGK BPM-8Y 0.65mm (0.026 in.)
Fuel ----------------------------------------------------------Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ----------------------------------------------- 50:1 two-stroke air cooled engine oil
Gasoline ----------------------------------------------------- 89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE.
Oil ------------------------------------------------------------ Power Blend
TM
Premium Universal 2-Stroke Oil
Fuel Tank Capacity ---------------------------------------- 0.45 lit. (15.2 US fl. oz.)
Recoil Starter System --------------------------------------Automatic Recoil Starter
Clutch -------------------------------------------------------Centrifugal Type
Drive Shaft -------------------------------------------------- 6.35 mm (1/4 in.) flexible shaft
Rotation Direction -----------------------------------------Clockwise viewed from right side
Edger Head ------------------------------------------------- Metal blade
Blade Length ----------------------------------------------- 203.2 mm (8.0 in.)
Blade Width ------------------------------------------------50.8 mm (2 in.)
Blade Thickness ------------------------------------------- 2.3 mm (0.090 in.)
Handle ------------------------------------------------------- D-loop, Right - Grip
Vibration Reduction --------------------------------------- Rubber Cushion
Idle Speed (RPM) ------------------------------------------2,500 - 3,300
Wide Open Throttle Speed (RPM) ---------------------- 10,000 - 11,500
