Echo PPT-2100 - Specifications

POWER PRUNER
OPERATOR'S MANUAL
13
MODEL
PPT-2100
PPT-2400
Length (Standard)
2286 mm (90.0 in.)
2743 mm (108.0 in.)
Length (Extended)
3410 mm (134.25 in.)
3886 mm (153.0 in.)
Width
222 mm (8.75 in.)
222 mm (8.75 in.)
Height
229 mm (9.0 in.)
229 mm (9.0 in.)
Weight (dry)
7.4 kg (16.3 lb.)
7.7 kg (16.9 lb.)
Engine Type
Air cooled, two-stroke, single cylinder gasoline engine
Bore
32.2 mm (1.268 in.)
34.0 mm (1.339 in.)
Stroke
26.0 mm (1.04 in.)
26.0 mm (1.04 in.)
Displacement
21.2 cc (1.29 cu. in.)
23.6 cc (1.44 cu. in.)
Exhaust System
Spark Arrestor Muffler
Carburetor
Diaphragm, w/primer bulb
Ignition System
CDI (capacitor discharge ignition)
Spark Plug
NGK BPM-7A
Gap 0.65 mm (0.026 in.)
NGK BPM-7Y
Gap 0.65 mm (0.026 in.)
Fuel
Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50:1 ECHO High Performance, two-stroke air cooled engine oil
Gasoline
89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE.
Oil
50:1 ECHO High Performance, two-stroke air cooled engine oil
Fuel Tank Capacity
0.4 lit. (14.0 US fl. oz.)
Starter System
Automatic Recoil Starter
Clutch
Centrifugal Type
Sprocket Type
6 tooth spur, 9.53 mm (3/8") pitch
Power Transmission Shaft Assembly
Aluminum Extrusion
Gear Case Ratio
1.5:1
Oiling System
Automatic
Saw Chain Oil Capacity
59 ml (2.0 oz.)
Handle
Right hand grip w/throttle trigger and lockout
Shoulder Harness
Standard
Idle Speed (RPM)
2600 - 3100
Wide Open Throttle Speed (RPM)
8000 - 9000
11,000 - 12,000
Guide Bar and Saw Chain (90SG)
254 mm (10 in.) ;
9.53 mm (3/8") pitch
305 mm (12 in.) ;
9.53 mm (3/8") pitch
SPECIFICATIONS
Specifications, descriptions and illustrative material in this literature are as accurate as known at the time of publication, but
are subject to change without notice. Illustrations may include optional equipment and accessories, and may not include all
standard equipment.
