PAS-266 SPECIFICATIONS
© 4/2013 ECHO Inc.
X7502026902 27
SPECIFICATIONS
MODEL PAS-266
Length 1010 mm (39.76 in.)
Width 250 mm (9.85 in.)
Height 250 mm (9.85 in.)
Weight (dry) 4.8 kg (10.6 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 34.0 mm (1.27 in.)
Stroke 28.0 mm (1.1 in.)
Displacement 25.4 cc (1.55 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPM-8Y (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X
TM
ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD, two-stroke,
air-cooled engine oil.
Gasoline
Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl
alcohol or 15% MTBE. Do not use alternative fuels such as E-15 or E-85.
Oil Power Blend X
TM
Premium Universal 2-Stroke Oil
Fuel Tank Capacity 0.5 lit. (16.9 US fl. oz.)
Starter System Automatic Rewind Starter
Clutch Centrifugal Type
Drive Shaft (upper & lower) 6.35 mm (1/4 in.) flexible shaft
Rotating Direction Counter Clockwise; viewed from top
Shoulder Harness Optional
Idle Speed 2,900 RPM
Clutch Engagement Speed 3,900 RPM
Wide Open Throttle Speed (W.O.T.) 9,500 RPM
