Echo Pro Attachment Series Service Data

3
PAS attachments
SERVICE INFORMATION
1-1 Specifications
Model Power Pruner
TM
attachment
Dimensions Shaft Length mm(in) 1455 (57.3)
Width mm(in) 70 (2.8)
Height mm(in) 127 (5.0)
Dry weight kg(lb) 2.0 (4.41)
Drive shaft 6.35 Flex shaft
Gear case Reduction ratio 1.5
Gear tooth Straight bevel gear
Lubrication Lithium based grease or ECHO LUBE
TM
Guide bar / Saw chain lubrication type Automatic
Tank capacity, oil cm
3
(U.S.fl.oz.) 59 (2.0)
Sprocket Type Spur
Number of teeth 6
Pitch in 3/8
Guide bar Type Sprocket nose
Called length cm(in) 25.4 (10)
Gauge in 0.050
Saw chain Number of drive links 39
Pitch in 3/8
Gauge in 0.050
Model Cultivator attachment
Dimensions Length mm(in) 889 (35.0)
Width mm(in) 165 (6.5)
Height mm(in) 220 (8.7)
Dry weight kg(lb) 1.95 (4.30)
Drive shaft 6.35 Flex shaft
Gear case Two stage
Reduction ratio 46
Gear Spur, Worm and wheel
Lubrication Lithium based grease or ECHO LUBE
TM
Blade diameter mm(in) 220 (8.7)
Cultivating width mm(in) 160 (6.3)
