Echo Pro Attachment Series Service Data

1 SERVICE INFORMATION
1-1 Specifications
Model Trimmer attachment
Dimensions Shaft Length mm(in) 870 (34.3)
Width mm(in) 280 (11.0)
Height mm(in) 255 (10.0)
Dry weight kg(lb) 1.5 (3.31)
Drive shaft 6.35 Flex shaft
Gear case Reduction ratio 1.36
Gear tooth Spiral bevel gear
Lubrication Lithium based grease or ECHO LUBE
TM
Cutter Type Nylon line cutter (2-lines)
Pilot diameter mm(in) 20.0 (0.79 )
Fastener type, size mm Left-hand thread, M10 x 1.25 pitch
Cutting rotation Counterclockwise as viewed from the output end
2
PAS attachments
SERVICE INFORMATION
Model Edger attachment
Dimensions Length mm(in) 790 (31.1)
Width mm(in) 170 (6.7)
Height mm(in) 275 (10.8)
Dry weight kg(lb) 2.3 (5.07)
Drive shaft 6.35 Flex shaft
Gear case Reduction ratio 1.57
Gear tooth Spiral bevel gear
Lubrication Lithium based grease or ECHO LUBE
TM
Cutter Type 2-tooth edger blade
Pilot diameter mm(in) 25.4 (1.00)
Fastener type, size mm Left-hand thread, M10 x 1.25 pitch
Cutting rotation Counterclockwise as viewed from the output end
Model Hedge Trimmer attachment
Dimensions Length mm(in) 1257 (49.5)
Width mm(in) 76 (3.0)
Dry weight kg(lb) 1.95 (4.30)
Drive shaft 6.15 Flex shaft
Gear case Reduction ratio 5.64
Gear tooth Spiral bevel, Spur
Lubrication Lithium based grease or ECHO LUBE
TM
Cutter Type Double reciprocating, double edge blade
Length mm(in) 511 (20.1)
Pitch mm(in) 35.0 (1.38)
Height mm(in) 21.0 (0.83)
Thickness mm(in) 2.5 (0.098)
