MAINTENANCE SRM-2320T
36 X7732278300
© 08/2019 ECHO Inc.
1. Remove spark plug lead.
2. Close choke (COLD START
[ ] position). This prevents
dirt from entering the
carburetor throat when the air
filter is removed. Remove air
cleaner cover (A).
3. Remove engine cover (B).
DO NOT use a metal scraper to remove dirt from the cylinder fins.
4. Use a brush to remove dirt
from the cylinder fins.
5. Remove ignition wires from
clip for cleaning.
To Next Page
