24
A
A
l u b r I c a t I o n
Level 1.
Tools Required: 8 & 13mm Open End Wrench, Screwdriver, Clean
Rag, Grease Gun
Parts Required: POWER BLENDX
TM
8 oz. (P/N 91014) or Lithium
Base Grease.
Gear Housing
1. Clean all loose debris from gear box.
2. Remove plug (A) and check level of grease.
3. Add grease if necessary. DO NOT over-ll.
Drive Shaft
(SRM-265 Only)
1. Loosen two (2) screws (B) and remove center locating screw (C).
Pull gear box and shield from drive shaft housing.
2. Pull exible cable from the drive shaft housing, wipe clean and
re-coat with a thin coating [15 ml (1/2 oz.)] of grease.
3. Slide the exible cable back in the drive housing. DO NOT get
dirt on the ex cable.
4. Install the gear housing and shield assembly.
IMPORTANT
Flat edge of washers (D) must be against drive shaft.
(SRM-265S Only)
No Lubrication Needed.
B
C
B
D
To Next Page
