OPERATION SRM-3020
24 X7502350002
© 2/20 ECHO Incorporated
Stored two-stroke fuel may separate. ALWAYS shake fuel container
thoroughly before each use.
Used oil and gasoline, and soiled towels are hazardous waste
materials. Disposal laws vary by locality.
Starting Cold Engine
The attachment will operate immediately when the engine
starts, and could result in possible serious injury. Keep
movable parts of the attachment away from objects that could
become entangled or thrown, and surfaces that could cause
loss of control.
If a protective blade cover is used, ALWAYS remove blade cover
before starting equipment.
1. Stop Switch
Move stop switch button (A)
forward, away from the STOP
position.
A
A

Echo SRM-3020 Specifications

General

Engine Displacement	30.5 cc
Shaft Type	Straight
Engine Type	2-stroke
Power Output	1.8 hp
Cutting Swath	17 inches
Cutting Width	17 inches
Handle Type	Loop
