MAINTENANCE SRM-3020
40 X7502350002
© 2/20 ECHO Incorporated
1. Press top of locking tabs (A) on
both sides of Speed Feed
®
head to
release cover (B) from
eyelet carrier (C).
2. Remove cover from eyelet
carrier.
Nylon Line Replacement
Wear gloves or personal injury may result:
◆ Cutoff knife is sharp.
◆ Gearcase and surrounding area may be hot.
1. Cut one piece of line to
recommended length.
2.0 mm (0.080 in.) diameter
7.6 m (25 ft.).
2.4 mm (0.095 in.) diameter
7.6 m (25 ft.).
2. Align arrows on top of knob with
openings in eyelets.
3. Insert one end of trimmer line
into an eyelet, and push line
equal distance through trimmer
head.
To Next Page
