Installing nylon line cutting head
1. Insert locking tool into a hole located on the right side of an-
gle transmission while forcing retainer spring to the left side.
2. Insert locking tool further into blade retainer fixing slot (A) to
fix output shaft.
3. Thread nylon line cutting head (B) onto shaft (anticlockwise)
until it is tight.
4. Remove locking tool (C).
U-handle version
U-handle assembly
1. Install handle assembling bracket (upper) (A) in handle as-
sembling bracket (lower) (D) and fix handle by tightening
handle assembling bolt (8 mm) (B) lightly.
2. Adjust inclination of handle to adequate position (easy to op-
erate) and tighten firmly handle assembling bolt.
C: Washer
E: Arrow
F: To engine
3. To eliminate loosening of throttle wire (I), fix it to shaft tube
(H) (2 places) and to right hand U-handle (1 place) with wire
fixing clips (G).
Installation of shield
1. Fit shield (A) to mounting portion of angle transmission and
tighten 4 bolts (B).
CAUTION
Fix output shaft securely using locking tool in order to
prevent it form rotating when nylon cutting head is
mounted.
CAUTION
Install the handle so that it does not hide any of the
safety decals.
