Echo TC-2100 User Manual

TILLER/CULTIVATOR
OPERATOR'S MANUAL
19
IMPORTANT
DO NOT use a metal scraper to remove dirt from the cylinder fins.
3. Use the wooden stick or brush to remove dirt from the cylinder
fins.
4. Remove grass and leaves from the grid between the recoil starter
and fuel tank.
5. When installing the cover, be certain the tab of the metal deflector
shield is in the slot of the cover.
EXHAUST SYSTEM
Spark Arrestor Screen
Level 3.
Tools Required: Cross Head Screwdriver. 3mm Hex wrench. Soft metal
brush. Wooden carbon scraper.
Parts Required: P/N 13001642031 Spark Arrestor Screen
P/N 14586642031 Screen Holder
1. Remove screen cover (A), screen holder (B), and gasket (C) from
muffler body.
2. Clean carbon deposits from screen (D) and muffler components.
3. Replace screen if it is cracked, plugged or has holes burned
through.
4. Install with new gaskets.
