TILLER/CULTIVATOR
OPERATOR'S MANUAL
9
SPECIFICATIONS
MODEL -----------------------------------------------------TC-210
Length------------------------------------------------------- 1130 mm (44.48 in.)
Width-------------------------------------------------------- 340 mm (13.36 in.)
Height -------------------------------------------------------1010 mm (39.76 in.)
Weight (dry) w/Tines ------------------------------------- 9.08 kg (20.0 lb.)
Engine Type ------------------------------------------------Air cooled, two-stroke, single cylinder gasoline engine
Bore ---------------------------------------------------------- 32.2 mm (1.268 in.)
Stroke--------------------------------------------------------26.0 mm (1.04 in.)
Displacement ----------------------------------------------- 21.2 cc (1.29 cu. in.)
Exhaust ------------------------------------------------------Spark Arrestor Muffler
Carburetor --------------------------------------------------Zama diaphragm model C1U w/primer bulb
Ignition System --------------------------------------------Flywheel magneto, capacitor discharge ignition type
Spark Plug -------------------------------------------------- NGK BPM-8Y Gap 0.65 mm (0.026 in.)
Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ----------------------------------------------- 50:1 ECHO High Performance, two-stroke air cooled engine oil
Gasoline ----------------------------------------------------- 89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE.
Oil ------------------------------------------------------------ 50:1 ECHO High Performance, two-stroke air cooled engine oil
Fuel Tank Capacity ---------------------------------------- 0.5 lit. (17.0 US fl. oz.)
Recoil Starter System --------------------------------------
- Start Automatic Rewind Starter
Clutch ------------------------------------------------------- Centrifugal Type
Gear Case --------------------------------------------------- Worm Gear Type (42:1 Ratio)
Tines --------------------------------------------------------Special 10 Tooth Design
Tilling/Cultivating -----------------------------------------229 mm (9 in.) x 15-20 mm (6-8 in.)
Tine Diameter ----------------------------------------------- 229 mm (9 in.)
Idle Speed---------------------------------------------------2,500 - 3,100 RPM
Wide Open Throttle Speed (W.O.T.) --------------------10,000 - 10,500 RPM
