HCS-2810 / 3810 CONTENTS
X7702248300 15
© 09/19 ECHO Incorporated
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your
convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer
or ECHO Dealer of damaged or missing parts. Use the contents list to check
for missing parts.
1. Purge Bulb
2. Choke
3. Air Cleaner
4. Spark Plug
5. Deflector Shield
6. Support Handle With Guard - For Right Hand
7. Recoil Starter Handle
8. Fuel Tank Cap
9. Fuel Tank
10. Throttle Handle - For Left Hand
11. Throttle Trigger Lockout
12. Stop Switch
13. Throttle Trigger
14. Spark Arrestor Muffler Or Spark Arrestor Muffler With Catalyst
15. Blades
16. Blade Guard
1 Hedge Trimmer Assembly
1 Operator’s Manual
1 Warranty Statement
1 Blade Cover
