HCS-2810 / 3810 MAINTENANCE
X7702248300 27
© 09/19 ECHO Incorporated
Air Filter
Level 1.
1. Close choke (COLD START
[ ] position). This prevents
dirt from entering the carburetor
throat when the air filter is
removed. Brush accumulated dirt
from air cleaner area.
2. Remove air filter cover. Brush dirt
from inside cover.
3. Replace filter if it is damaged,
fuel soaked, very dirty, or the
rubber sealing edges are deformed.
• Lightly brush debris from filter.
• Soak heavily soiled filters in water/detergent solution to loosen dirt,
then brush lightly.
• Rinse with clean water and allow to dry completely before reuse.
4. Install air filter in air filter case.
5. Install air filter cover.
Fuel Filter
Level 1.
Fuel is VERY flammable. Use extreme care when mixing, storing
or handling, or serious personal injury may result.
Parts Required: Tune Up Kit
Parts Required: TUNE UP KIT.
