Wiring Diagram
FC-CHMSL-SIL
Integrated Towing Assistance Package
Part No Description Qty
1 FC-GMS-TC Main Interface module 1
2 GMSWRBRKT-1 Main Interface bracket 1
3 BSM1-PTH Power T-harness 1
4 BSM1-CEH Camera extension harness 1
5 BSM-WCEH-D 3657mm/114” Camera extension harness 1
