Installation Guide
5
email - gmsupport@echomaster.com (US) - tel - 866-766-2267
Illustrations are typical and may not match exact vehicle details.
4
email - gmsupport@echomaster.com (US) - tel - 866-766-2267
Illustrations are typical and may not match exact vehicle details.
Step 4
Disconnect the 3 connectors from the back
of the LCD display assembly and set aside.
Steps 5 & 6
Remove the 2 x 7mm bolts from the
CD mechanism.
Disconnect the CD mechanism and
set aside.
Step 7
Remove the 4 x T-15 torx screws from the
glove compartment (2 from top and 2 from
bottom).
Remove the glove compartment and set
aside.
FC-CHMSL-SIL
Integrated Towing Assistance Package
