Installation Guide
6
email - gmsupport@echomaster.com (US) - tel - 866-766-2267
Illustrations are typical and may not match exact vehicle details.
Installing CHMSL Camera
Step 1
Remove the 2 x T15 torx screws
that secure third brake light.
Step 2
Grab the light at the bottom and pull
up and out, then disconnect the gray
connector on the back.
Step 3
Attach the CHMSL camera housing by
rst removing 2 x Phillip’s screw and
removing the top cap. Then snap in
place onto back of the brake light.
Once it is snapped in place
reinstall the top cap on to the camera.
FC-CHMSL-SIL
Integrated Towing Assistance Package
