Installation Guide
7
email - gmsupport@echomaster.com (US) - tel - 866-766-2267
Illustrations are typical and may not match exact vehicle details.
6
email - gmsupport@echomaster.com (US) - tel - 866-766-2267
Illustrations are typical and may not match exact vehicle details.
Step 4
Pull away the passenger side top
rear portion of the door seal.
Remove the front and rear passenger
door sill as well as the passenger
side kick panel cover.
Step 5
Tape short camera extension cable to a
long zip tie or exible wire shing tool.
Fish from the brake light to rear top corner
of passenger’s C pillar cavity between
headliner.
Step 6
Thread extension onto the camera cable and
then remount brake light with camera
attached using the 2 x T15 Torx screws.
FC-CHMSL-SIL
Integrated Towing Assistance Package
To Next Page
