operation and with long cable runs, the cables between the amplifier and the
speakers should be as short as possible and have good quality.
ATTENTION: The AMBIT103 are shipped from factory with the switch in 100V/15W
position. If it is connected to a low-impedance amplifier, the speaker will not be
damaged, but will perform way below its full potential. If the speaker is accidentally
connected to a 100V line in the 8/25W position, it will be severely damaged.
Always respect polarity. All connections are on spring-loaded terminals.
6. PLACEMENT AND MOUNTING
Consider following general rules:
• Place the acoustic enclosures on solid and firm surfaces.
• No obstacles should stand between the enclosures and the audience.
• Although the speakers can be used outdoors, they should not be directly
exposed to sunlight or rain.
• Always adjust the output sound pressure levels to the reproduction
requirements. Despite their small size, they can produce significantly higher
pressure levels than home speakers.
The AMBIT packaging contains everything you need to install the enclosure:
• Two brackets.
• Allen screws to anchor the box.
• Miscellaneous screws and rawlplugs for the wall.
• Safety runners.
• One L-shaped Allen wrench.
Speaker cables can be hidden from view by choosing an adequate mounting
orientation. Although the inconspicuous AMBIT logo suggests mounting the unit with
the input connectors on the upside and the selector switch on the downside, the
enclosure can be mounted in any orientation because the high frequency driver is
concentric and the adhesive logo can be positioned anywhere.
