Ecler eAMBIT103 - Technical Characteristics

9
7. TECHNICAL CHARACTERISTICS
eAMBIT103
System
Effective frequency range
1
150Hz - 20kHz
Coverage angle
2
207°x207° (HxV)
Power handling
25 W RMS / 100 W Peak
Sensitivity
3
87 dB (1W/1m)
Maximum SPL
4
101 dB continuous / 107 dB Peak
Power options
70/100V: 15W / 7,5W / 5W / 2,5W / 8Ω
Recommended amplifier power
50 W RMS
Transducers
Ways
2
Low frequency driver
3,5" woofer
High frequency driver
0,5 tweeter"
Nominal impedance
8Ω
Physical
Connection type
Spring loaded input terminals
Environmental
IP54 rated
Mounting system
Cabinet
Included accessories
Includes on-wall hardware, safety sling,
screws and wrench for fast installation
Finished colour
White (RAL 9016) or black (RAL 9005)
Dimensions (WxHxD)
Without accessories: 120 x 120 x 118 mm /
4.72 x 4.72 x 4.65 in.
Weight
1.275 kg / 2.81 lb
1
3dB below the sound pressure level at specified sensitivity
2
6dB below the sound pressure level than that at the direction of maximum level, Max. angle between 1 kHz and 4
kHz.
3
Measured on-axis, far field and referenced to 1 meter by inverse square law. Average from 100 Hz to 10 kHz.
4
Calculated from sensitivity and power handling specifications, exclusive of power compression
