Ecler MPA4-150 - Page 116

author: Queralt date: 000728
approved:
num:
40.0046 version: 01.01
C156 100n FCXCN41000
C157 100n FCXCN41000
C158 100n FCXCN41000
C159 100n FCXCN41000
C160 47u/16 FCCE100000
C161 47u/16 FCCE100000
C162 47u/16 FCCE100000
C163 47u/16 FCCE100000
C164 47u/16 FCCE100000
C165 47u/16 FCCE100000
C166 47u/16 FCCE100000
C167 47u/16 FCCE100000
CI101 11.0768 FCCIMPA768
D101 BAS16 FCXDDBAS16
D102 BAS16 FCXDDBAS16
D103 BAS16 FCXDDBAS16
D104 BAS16 FCXDDBAS16
D105 LED3G FCLED300VE
D106 LED3G FCLED300VE
D107 LED3G FCLED300VE
D108 LED3G FCLED300VE
D109 LED3Y FCLED300AM
D110 LED3R FCLED300RO
D111 LED3R FCLED300RO
D112 LED3R FCLED300RO
D113 LED3R FCLED300RO
IC108 TL072 FCIC072010
IC109 TL072 FCIC072010
R171 10kAx2 FCPR210040
R172 10kAx2 FCPR210040
R173 10kAx2 FCPR210040
R174 10kAx2 FCPR210040
R175 475k FCXR154750
R176 20k0 FCXR142000
R177 475k FCXR154750
R178 20k0 FCXR142000
R179 1k0 FCXR131000
R180 1k0 FCXR131000
R181 1k0 FCXR131000
R182 1k0 FCXR131000
R183 1k0 FCXR131000
R184 1k0 FCXR131000
R185 1k0 FCXR131000
R186 1k0 FCXR131000
R187 340k FCXR153400
R188 340k FCXR153400
R189 340k FCXR153400
R190 340k FCXR153400
R191 1k50 FCXR131500
REFERENCE VALUE CODE
PARTS LIST
PRINTED CIRCUIT 11.0768-04.00
model:
EP05-99
E
C
LER
40-0046-0101 EP05-99.xls SHEET 1 OF 2
