author: Queralt date: 000728
approved:
num:
40.0047 version: 01.00
C101 C100n FCCC151010
C102 C100n FCCC151010
C103 2200u/35V FCCE212200
C104 10000u/63 FCCE321000
C105 10000u/63 FCCE321000
C106 10000u/63 FCCE321000
C107 10000u/63 FCCE321000
C108 C100n FCCC151010
C109 C100n FCCC151010
C110 2200u/35V FCCE212200
C111 C100n FCCC151010
C112 C100n FCCC151010
CI101 11.0769-01.02 FCCIMPA769
D101 B250C1000 FCREC25100
D102 1N4007 FCDD140070
D103 FB5006 FCREC50060
D104 1N4007 FCDD140070
HS100 HEAT SINK FCRAD11515
HS101 HEAT SINK TO220 FCMECT0220
HS102 HEAT SINK TO220 FCMECT0220
IC101 7815 FCREG78150
IC102 7915 FCREG79150
J101 BASE 9pins MALE FCCTAMP090
J102 BASE 4pins MALE FCCTAMP040
J103 BASE 4pins MALE FCCTAMP040
J104 YKD31-0496 FCCTJAL100
J105 YKD31-0496 FCCTJAL100
J106 B3B-EH-A FCCTM00030
S101 17128 FCINTD4000
SC100 Screw M4x12 TR FCT3804012
TS101 IB.311 FCTERMSOL0
W100 19mm FCMECPON19
W101 7.5mm FCPONT0075
W102 19mm FCMECPON19
W103 7.5mm FCPONT0075
W104 7.5mm FCPONT0075
W105 7.5mm FCPONT0075
WI101 1016.03.50 FC2F016350
WI102 1017.03.50 FC2F017350
WI104 1012.01.00 FC0C012100
WI106 1007.02.00 FC4K007200
WI107 1020.03.30 FC0H020330
WI108 1020.03.30 FC0H020330
WI109 1020.03.30 FC0H020330
WI110 1020.03.30 FC0H020330
WI111 1020.03.30 FC0H020330
WI112 1020.03.30 FC0H020330
WI113 1020.03.30 FC0H020330
WI114 1020.03.30 FC0H020330
WI115 1020.03.30 FC0H020330
REFERENCE VALUE CODE
PARTS LIST
PRINTED CIRCUIT 11.0769-01.02
model:
EP05-99
E
C
LER
40-0047-0100 EP05-99.xls SHEET 1 OF 1
