Ecler MPA4-150 - Page 148

drawn: date:
040210
number:
32.0049
version
01.02
PACKING DIAGRAM EP05-99
approved by:
Jordi Folc
h
title:E
C
LER
6
4
9
1
11
1
4
1
3
2
5
1
7
1
12
1
13
4
1
4
2
4
8
4
14
1
Nº Qty Code Description
1 4 FCARAT300000 SCREW INSULATOR
2 4 FCARN5000000 WASHER 5X11,5X0,8
3 2 FCBOL0010000 BAG 60x80
4 1 FCBOL0020000 PLASTIC BAG 120x180
5 1 FCBOLS020000 STANDARD BAG 75x65
6 4 FCBOTD240100 ROT. KNOB PROTECTION COVER
7 1 FCCAJSTA0100 BOX STANDARD 1
8 4 FCCANT118000 INTERIOR REINFORCEMENT
9 1 FCCONX017500 MAINS CABLE 3x1
10 1 FCETI0951140 PRODUCT LABEL PACK (ONE FOR EACH UNIT)
11 1 FCFUNMAN0000 USER MANUAL BAG
12 1 FCMANMPA7000 USER MANUAL MPA 70W
13 4 FCPIE1125500 RUBBER FOOT
14 1 FCTARJG00000 WARRANTY CARD
