Ecler PAM4100 - 8 Caractéristiques Techniques; 8 Características Técnicas; 8 Technical Characteristics; 8 Technische Daten

41
8. TECHNICAL CHARACTERISTICS 8. CARACTERÍSTICAS TÉCNICAS
8. CARACTÉRISTIQUES TECHNIQUES 8. TECHNISCHE DATEN
MODEL PAM1100
PAM2100
PAM4100
PAM6100
Output Power (*) WRMS@ 1kHz/ 1% THD
2
Ω
Peak Power
1180 W 2200 W 3650 W 5900 W
2
Ω
Stereo
495 W 1050 W 1580 W 2600 W
4 Ω Stereo
354 W 670 W 1100 W 1750 W
8 Ω Stereo
218 W 385 W 650 W 1050 W
8
Ω
Bridged
710 W 1340 W 2200 W 3500 W
16 Ω Bridged
440 W 780 W 1300 W 2100 W
FEATURE
Frequency. Response @ max. Output power (-1dB) 6Hz-80kHz 6Hz-80kHz 6Hz-90kHz 6Hz-95kHz
Subsonic filter Butterworth 2
nd
order (-3 dB) 20 Hz., 30 Hz., 40 Hz., OFF
Harmonic Dist.+Noise @ 1kHz Max. power < 0.04% < 0.04% < 0.07% < 0.07%
Intermod.Dist.(50Hz & 7kHz 4:1 ratio)@nom. out power < 0.03% < 0.03% < 0.08% < 0.08%
TIM 100 < 0.02% < 0.01% < 0.04% < 0.04%
Signal/ Noise ratio 20Hz-20kHz ref. 1W/4Ω
> 87 dB > 85 dB > 84 dB > 84 dB
Signal / Noise ratio 20Hz-20kHz nom. power @ 4Ω
> 112 dB > 113 dB > 114 dB > 116 dB
Damping factor @ 1kHz/8Ω
> 300 > 320 > 320 > 370
Slew Rate
± 90 V/µs ± 120 V/µs ± 125 V/µs ± 135 V/µs
Channel Crosstalk > 70 dB > 70 dB > 74 dB > 74 dB
Input CMRR @ 1 kHz (dB below nom power @ 4
Ω
)
> 60 dB > 60 dB > 64 dB > 70 dB
Input sensitivity / impedance
0dBV/>20kΩ
Anticlip 1 & 4 % THD Intelligent A
2
SP
Input connector XLR-3 balanced
Output connector SPEAK-ON
Power consumption @ max.Output / 4Ω
1390VA 2590VA 4000VA 6260VA
Front panel dimensions w x h 482.6x88 482.6x132.5
Chassis dimensions w x h x d 440x88x420mm 440x132.5x523mm
Weight 16.3 Kg 20.4 Kg 26 Kg 31.5 Kg
(*) Both channels operating. Peak power: one channel operating.
