Eclipse Bi-Flame v1.8, Instruction Manual 826, 05/03
8
INTRODUCTION
Specifications
This section gives a detailed overview of Bi-Flame specifications and
dimensions.
2
Specifications
Parameter Description
Supply •120 VAC (+10%, -15%), 50/60 Hz standard.
Internal power consumption: 24VA
Temperature Ranges Unit Model Nos. Temperature Range
Bi-Flame 6500 -40˚ to +60˚C (-40˚ to +140˚F)
90˚ U.V. Scanner 5600-90A -20˚ to +60˚C (0˚ to 140˚F)
U.V. Scanner 5600-91 -40˚ to +125˚C (-40˚ to +257˚F)
NEMA4 UV Scanner 5600-91N4 -20˚ to +125˚C (0˚ to 257˚F)
Self-Check U.V. 5602-91 -40˚ to +60˚C (-40˚ to +140˚F)
Remote Display 6000D 0˚ to 50˚C (32˚ to 122˚F)
Flame Failure Response • 3 seconds ±0.5 seconds.
TFI/Pilot Interrupt • 5, 10 or 15 seconds selectable.
Purge Time • Modulating: selectable from 0-225 seconds in 15 second increments,
or 0-15 minutes in 1 minute increments
• Process: selectable from 0-15 minutes in 1 minute increments,
or 0-60 minutes in 4 minute increments.
Contact Ratings @ 120 VAC Function Affected Terminals Inductive Load Resistive Load
(maximum total connected Output Relay J2-4 through J2-8 1/3 HP 10 amps
load not to exceed 15 amps) Output Relay J2-3 1/2 HP 15 amps
Modulation J3-1 through J3-4 1/3 HP 10 amps
Approvals • UL Recognized; File MP1537 (category MCCZ2)
• FM Approved; J.I. 2Y3A5.AF (class 7610)
• CSA Certified; File 007989-0-000 (class 2632-01, 2642-01)
Shipping Weight • 2.7 kilograms (6 lbs.)
