Wire colors and connection points for connection wires

Never connect the power supply to the speaker wires (No.7 and No.8),

otherwise it will cause damage to the main unit.

Caution

ACC (Red)

Connect where the power comes on when the ignition is in the ACC position.

B+ (Yellow)

Connect where power is constantly available, regardless of the ignition key's position.

Ground (Black)

Connect where good body grounding is available.

Antenna power supply (Blue)

Connect to the automatic-antenna control terminal of the vehicle.

Illumination power supply (Orange/White)

Connect to where power comes on when the vehicle light switch is turned on.

Control power supply (Blue/White)

Connect the control terminal for the external amplifier, etc.

Front speaker output wires

Connect to the front speakers. White: Left + White/black: Left -

Gray: Right + Gray/Black: Right -

Rear speaker output wires

Connect to the rear speakers. Green: Left + Green/black: Left -

Purple: Right + Purple/Black: Right -

Genuine factory steering remote control terminal

Connect to the vehicle steering remote control.

※

Compatible vehicle models for installation : Vehicles with voltage detection-type steering remote control.

Ask your dealer for details.
