Introduction
1.1 Camera Highlights
Responsivity
• 1950 DN/(nJ/cm
2
) nominal responsivity
• 100x more responsive than standard line scan cameras
• Ideal for applications with low-intensity, low-cost lighting
Size
• Small form factor: 50mm x 50mm x 88mm, <350g
• C-mount optics for 512 & 1024; F-mount for 2048
Performance
• 40MHz single output data rate
• 8-bit output from 10-bit digitization
• 512, 1024 and 2048 pixels, 13µm x 13µm, 100% fill factor
• Line rates up to 64kHz
• 96 TDI stages
• Bidirectional
• RS-644 (LVDS) data format
Programmability
• Simple ASCII protocol controls binning, gain, offset, line and data rates, trigger mode,
direction, pixel correction, test pattern output, and camera diagnostics.
• RS-232 interface (ASCII, 9600 baud)
Usability
• Programmable gains, offsets, and camera controls
