Features
WARNING: All adjustments must not be made while user is seated on Powerchair.
All other adjustments should be carried out while seated in your Powerchair.
Footrest Angle Adjustment
1. Flip-up the footplate for easy access to bolt.
2. With an Allen wrench, simple turn the bolt clockwise to
increase the angle or counter-clockwise to decrease the
angle.
A. Hold hexagonal bolt with wrench and loosen the
nut.
B. Choose the correct angle and tighten the bolt.
Armrest Angle Adjustment
1. Flip up the armrest for easy access to the set screw.
2. Turn the set screw counter-clockwise to raise the armrest and
clockwise to lower the front of the armrest.
Headrest Height Adjustment
Depress then release the clamp on the left of the backrest while pulling
headrest up or pushing down until you reach the desired comfort position.
(one of three).
