Eclipse WX Series User Manual

Eclipse Winnox WX Series v1 Design Guide No. 111, 9/25/2008
10
Combustor Type
Select a combustor type based on the application:
Recommended Maximum Chamber Temperature °F (°C)
Model
Standard
Alloy Tube
High Temp
Alloy Tube
Refractory
Plug
100, 200 1300° (704°) 1550° (843°) 1800° (982°)
300, 400 1300° (704°) 1550° (843°) 1800° (982°)
500, 600 1300° (704°) 1550° (843°) 1800° (982°)
1000 1100° (593°) 1400° (760°) Not Available
Tube and plug temperatures should be reduced 150°F when using
propane or butane.
Note:
When using a refractory plug, the customer must provide
their own refractory tube set up per Eclipse dimensions.
Control Motor
Select a control motor. Standard control motor options include
various models which Eclipse will mount to the burner. Winnox
burners can be ordered with control motor bracket and mounting
hardware only. Customer supplied control motors must conform to
these specications:
rotation not to exceed 2 rpm•
minimum torque of 25 in-lb (2,8 Nm)•
90° stroke•
continuous modulating or high/low modulating control•
reversible direction of rotation•
certain applications may require control motors with a limit •
switch or switches if:
- the burner capacity is to be limited to t an application
- the chamber is to be red with positive or negative
pressure
- the chamber pressure is outside the range -1" w.c.
to +1" w.c. (-2,5 to 2,5 mbar)
- there is a need to indicate a high and/or low re air
buttery valve (BV) position
Burner Conguration
Select conguration. See gure 3.2 on page 11 for illustrations.
Gas Pipe Connection
Select the gas pipe connection including the pipe thread type.The
piping, burner gas inlet, and fuel train components are threaded
using the customer selected pipe thread option.
Flame Supervision
Select a ame rod or an ultraviolet (UV) scanner. Both are
available on all Winnox burners. If a ame rod is selected, it will be
factory mounted in the burner. If a UV scanner is selected, it must
be ordered separately.
Warning:
A UV scanner can possibly detect another burner’s
ame if it is in the line of sight, and falsely indicate
ame presence. Use a ame rod in this situation. This
helps prevent accumulation of unburned fuel which,
in extreme situations, could cause a re or an
explosion.
Step 1: Burner Option
Selection (Continued)
