Eclipse Winnox WX Series v1 Design Guide No. 111, 9/25/2008
System Design
Design Structure
The design process is divided into the following steps:
Burner Option Selection Including:1.
Burner Model / Size Selection•
Fuel Type•
Air Supply•
Combustor Type•
Control Motor•
Burner Conguration•
Gas Pipe Connection•
Flame Supervision•
Air Flow Switch•
Blower Option Selection Including:2.
Power Supply Frequency•
Pressure and Flow•
Blower Motor Type•
Blower Inlet•
Motor Orientation•
Control Methodology Including:3.
Burner Control•
Ignition System Including:4.
Ignition Transformer•
Trial for Ignition•
Flame Monitoring Control System Including:5.
Flame Sensor•
Flame Monitoring Control•
Main Gas Shut-Off Valve Train Including:6.
Component Selection•
Valve Train Size•
Verify Chamber Design7.
Firing Chamber Dimensions•
De s i g N
3
