E C O P H Y S I C S RS-232 interface
CLD 780 TR / July 2000 109
SA m,o,f Set analog output mode 4*)
m: mode 0 = 0 ... 1 V
1 = 0 ... 10 V
2 = 0 ... 20 mA
o: offset 0 = 0 %
1 = 20 %
f: Range 0 = 100 %
full-scale 1 = 50 %
SY yy,mm,dd,hh,mm Set date and time 4*)
(year, month, day, hour, minute)
SS n Activate ”Standby“ operation 2,4*)
n: 1 = Standby (ozone generators off)
0 = return to measure mode (i.e. restart
instrument)
2 = Clear instrument error or warning
with highest priority (fatal error pro-
duces a restarting of the CLD 780
TR)
SC i,r,xxxxxx Enter calibration coefficients 2,4*)
(only for internal use!)
i: 0 = fNO; 1 = W
K
; 2 =
λ
NO; 3 = ZERO
net
r: Measurement range [0...4], 5 = Cont.Meas
fNO: xxxx.x [cps/ppb] ≤ 3199.9
W
K
: x.xxxx ≤ 9.9999
λ
NO: x.xxxx ≤ 2.0000
ZERO
net
: xxxxxx [cps] ≤ 999999
SF i,xx.. Enter data filter type 4*)
i: 0 = Slide; 1 = Fastav.; 2 = Slowav.
Slide: xxxx [s] (0 = off) ≤ 1001
Fast average: xx [s] (0 = off) ≤ 61
Slow average:xxxx [s] (0 = off) ≤ 121
SX n,xxx. Enter AICI and Calibration parameters 4*)
n: 0 = AICI Time; 1 = CAL. & AICI Int.;
2 = Purge; 3 = Rea. Delay
AICI Time: xxxx [s] (0 = off) 0012 ... 9999
CAL. & AICI I: xxx [s] 003 ... 120
Purge: xxx [s] (0 = off) 000 ... 255
Rea. Delay: xxxx [ms] 0020 ... 9999
HC Leave current measurement cycle 4,12*)
HS Start measurement cycle 2,4,12*)
Note: Each measurement cycle must be initiated (i.e. syn-
chronized) using the HS command.
