E C O P H Y S I C S Installation
CLD 780 TR / July 2000 26
4.1 Unpacking
Please check when unpacking that all the parts listed below are present
and show no sign of transport damage. The numbers in brackets behind
each listed item refer to Fig. 4.2.
– 1 CLD 780 TR NO analyzer
– 4 rubber instrument feet
– 1 operating manual (Handbook)
– 3 silica gel drying columns [F], for the oxygen and dry air supplies
– 2 connecting tubes (from silica gel cartridge to CLD 780 TR [4], [6], Ø
10 x 6 mm x 1.5 m, PVC, with 1/4” steel tube fitting
– 2 spare ferrules for 1/4” Swagelock fittings
– 1 chart recorder cable [14]
Plug color coding:
NO signal: red
NO.c signal: blue
NO
2
signal: yellow
Ground: black
– 1 power cable [12]
– 1 interface cable [16]
