14
DIVERTER VALVE
OZONE JET
SUCTION FITTINGS
LED LIGHTING
TROUBLESHOOTING
The 3-position DIVERTER VALVE allows water to be diverted to a zone of
jets, if desired. When the “Pointer Arrow” of the Diverter Valve is
centered in the middle (pointed towards the inside of the spa) water
flow is directed to all jets. Turning the Pointer Arrow of the Diverter
Valve knob all the way to the right or all the way to the left diverts all
water flow to a zone of jets on one side of the spa or the other resulting
in more robust massage jet action from that zone of jets.
The special 2” OZONE JET, if so equipped, located low in the footwell
area of each ECO SPA, has a fixed position nozzle; its jetstream
cannot be aimed and its flow pressure cannot be adjusted like the
massage jets.
Whenever the pump is running, this jet serves as a virtual foot
However, its true purpose is to introduce Ozone into the water supply during an active Filter
Cycle. Venturi action feeds Ozone from the Ozone Generator unit into this jet’s water supply and
the Ozone jet in turn releases it into the water to aid in sanitizing by killing and breaking down
certain organic materials.
Keep the SUCTION FITTINGS (located in the foot well area) of the ECO SPA
unobstructed and free from debris at all times.
Do not remove the suction-fitting screen while the ECO SPA is connected to
electrical power.
The LED LIGHTING in your ECO SPA provides you with a
variety of colorful mood lighting options with its 9-LED 12
volt master bulb, ranging from solid colors to various multi-
color sequence ”light shows”. Push the LIGHT BUTTON once
on the TOPSIDE CONTROL PANEL to turn the lighting system
ON and once again to turn it OFF.
Each successive ON-OFF operation of the LIGHT BUTTON will change the lighting from one solid
color to another and eventually to cycle through the ‘light show’ variations and then Off.
A built-in timer automatically turns off the LED LIGHT after 2 hours of continuous operation.
