Eco Spa E6 - Page 19

19
The settings values displayed by the system correspond to 80% of the GFCI’s maximum amperage
capacity. This allows ‘headroom’ to protect the system equipment from current “spikes.”
Now rotate the dial to
“Number of phases’ showing
‘1’, Press to confirm, then
rotate the dial to Code, enter
Code 5-5-5-5 & Press the
button once to set the rating
and exit this task.
Next, Rotate the dial to scroll thru various Breaker Settings:
The Breaker Setting should be set
at 16 if your ECO SPA was set at
the factory for 110 Volt operation.
If your ECO SPA was set at the
factory to operate on 220 Volts the
Breaker Setting will read 40. If you
are converting your ECO SPA from
110 Volt to 220 Volt operation,
adjust the setting from 16 to 40.
NEXT:
Rotate the Dial to Elec. Config., then press & Rotate the Dial to Input Current
