ECT Install and User Guide
Feb 2023
4 of 61
ECOER INC.
Manufacturer reserves the right to change specifications or designs without notice.
No.
Name
Qty.(embeded
into wall)
Specification
(only for reference)
Remarks
1
Switch box
1
2
Wiring Tube(Insulating
Sleeve and Tightening
Screw)
1
Precaution of installing the wire controller
1. This manual provides the installation method of wired controller.
Please refer to the wiring diagram of this installation manual to
connect the wire controller with indoor unit.
2. The wired controller works in low voltage loop circuit. Forbid to
directly contact the cable of high voltage above, like
115V,220V,380V, and don’t wire this kind of wire in the said loop;
wiring clearance between configured tubes should be at the
range of 300~500mm or above.
3. The Sh
ielded wire of the wired controller must be grounded
firmly.
4. Upon fi
nish the wire controller connection, do not employed
tram egger to detect the insulation.
2. 2 Prepare the following assemblies on the site.
