Ecoer ECT01 - Installation Method; 3.1 Structural Dimensions; 3.2 Remove Upper Part

ECT Install and User Guide
Feb 2023
5 of 61
ECOER INC.
Manufacturer reserves the right to change specifications or designs without notice.
Fig 3-2
Fig 3-1
19mm84mm
46mm
60mm
44mm
120mm
120mm
Back cover
20.6mm
Buckling
position
• Insert a slot screwdriver into the
slots in the lower part of the wired
controller (2 places), and remove
the upper part of the wire
controller. (Fig.3-2)
3.1 Wired remote controller structural dimensions
3. Installation method
3.2 Remove the upper part of wired controller
NOTE : Do not pry up and down, you can only rotate the screwdriver.
