pag.23
LB1122 Minor 1.1/1.1 R
B
TC = SHORT HEAD TL = LONG HEAD
MINOR 1.1 MINOR 1.1 R
N° DESCRIPTION code code
1 - OIL PUMP SUNTEC AS 47 K P122 P122
Danfoss BFP21 R3 P121/71 P121/71
2 - COIL SUNTEC V504 V504
DANFOSS V510/2 V510/2
3 - OIL VALVE SUNTEC V410 V410
DANFOSS V412/1 V412/1
4 - COUPLING AEG MP504 MP504
5 - NIPPLE BFR01103/001 BFR01103/001
6 - HOSES TN 6 x 700 S906 S906
7 - FILTER ART.70451 S105 S105
8 - COVER BFC09009 BFC09009
9 - MOTOR 75 W AEG M181/1 M181/1
10 - CAPACITOR 3 µF x 75 W AEG C107/9 C107/9
11 - IGNITION TRANSFORMER COFI E820 CM T120 T120
Danfoss CM T130/1 T130/1
12 - CONTROL BOX BASE LANDIS A402 A402
13 - CONTROL BOX LANDIS LOA 24 A117/1 A117/1
14 - PHOTORESISTOR LANDIS A208/3 A208/3
15 - WIRING TERMINAL BOX E228/2 E228/2
16 - PROTECTION BOX BFC09011/1 BFC09011/1
17 - FAN 99 x 43 BFV10001/001 BFV10001/001
18 - AIR CONVEYOR GRMP002 GRMP002
19 - AIR DAMPER - -
20 - COVER AIR INLET GRCA030 GRCA030
21 - CABLES TC BFE01401/1 BFE01401/1
TL BFE01401/2 BFE01401/2
22 - ELECTRODES BFE01101 BFE01101
23 - BLAST TUBE TC BFB01303/102 BFB01303/102
TL BFB01303/202 BFB01303/202
24 - FIRING HEAD TC
TL
25 - NOZZLE HOLDER SUPPORT BFC10020/001 BFC10021/001
26 - NOZZLE HOLDER BFC11016 -
Danfoss 030N2504 - PP110/3
27 - DIFFUSER BFD04005/001 BFD04005/001
28 - ROD TC BFA05003/101 BFA05003/101
TL BFA05003/201 BFA05003/201
29 - GASKET BFG02008/1 BFG02008/1
30 - FLANGE BFF01001 BFF01001
31 - GASKET BFG02007 BFG02007
32 - FAN SCOOP BFC02040 BFC02040
33 - ANTIJAMMING FILTER D.E.M. S132/3 S132/3
34 - PROTECTION BFC03039/5 BFC03039/5
35 - MOTOR FLANGE BFF03005/001 BFF03005/001
