EcoFlow EF DELTA User Manual

Master unit AC on
Slave 1 Slave 2
Example 2 :
100%
12V CAR
AC ON/OFF
100%
12V CAR
AC ON/OFF
100%
12V CAR
AC ON/OFF
Net Weight
Dimension
Capacity Delta 1300 / Delta 1600
Testing and certification
30.9lbs (14kg)
15.7 x 8.3 x 10.6in (40 x 21 x 27cm)
1260Wh 50.4V / 1657.6Wh 51.8V
UL CE FCC RoHS PSE RCM AS/NZS 3820:2009
General Specs
TECHNICAL SPECIFICATIONS
AC Output (x6)/AC Output (x4)
USB-A Output (x2)
USB-A Fast Charge (x2)
USB-C Output (x2)
Car Power Output (x1)
Output
5V DC, 2.4A, 12W Max, per port
5V DC, 9V DC, 12V DC, 2.4A, 28W Max, per port
5V DC, 9V DC, 15V DC, 20V DC, 3A, 60W Max, per port
108.8W, 13.6V DC, 8A max
1800W (Surge 3300W)total, 230Vac (50Hz)
AC Charge Input Voltage
AC Charge Input Power
Solar Charge Input
Car Charger(Example 2)
Input
X-STREAM Charge 1200W max
400W 10-65V DC 10A max
12V/24V DC 10A max
220-240Vac
Cell Chemistry
Cell Type
Discharge Temperature
Charge Temperature
Shelf Life
Life Span
Battery
Lithium-ion
18650
-20-45°C
0-45°C
1 Year (After fully charged)
800 Cycles (60%)
13
power a free life

EcoFlow EF DELTA Specifications

General

Battery Capacity	1260Wh
AC Charging Input Power	1200W Max
Recharge Time	1.6 hours (AC)
Weight	30.9 lbs (14 kg)
Dimensions	15.7 x 8.3 x 10.6 in (40 x 21 x 27 cm)
Charging Temperature	32 to 113°F (0 to 45°C)
Cycle Life	800 cycles to 80% capacity
Operating Temperature	32 to 113°F (0 to 45°C)
AC Output	1800W (Surge 3300W)
USB-A Output	2 x 5V/2.4A, 12W Max per port
USB-A Fast Charge	2 x 5V, 2.4A / 9V, 2A / 12V, 1.5A (18W Max)
USB-C Output	2 x 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A, 100W Max per port
Solar Input	400W, 10-65V, 10A
Car Charger Input	12/24V, 8A
Input Voltage	100-120V (US/JP) / 220-240V (EU/UK/AU)
Discharging Temperature	-4 to 113°F (-20 to 45°C)
