6.3 Electrical data
Electrical data for the Reed switch: 42 V, 0,5 A, 10 W / 12 VA
6.4 Suction lance key
The suction lance key comprises three groups:
n Group I: Description/material
Ä ‘Suction lance key: Group I’ on page 23
n Group II: Technical data
Ä ‘Suction lance key: Group II’ on page 23
n Group III: Equipment
Ä ‘Suction lance key: Group III’ on page 24
Example
Description/material Technical data Equipment
1 2 3 4 5 6 7 8 9 10 11 12 13
SGL VC VC FP FP KE 000 G2 25 2SS 1200 99 99
Complete key: SGL VC VC FP FP KE 000 G2 25 2SS 1200 99 99 (Mat. no. 250052)
Suction lance key: Group I
"Description/material" [SGL|VC|VC|FP|FP|KE]
No. 1: ‘Description’
SGL Suction lance
No. 2: ‘Material for suction lance pipe/float
’
VC PVC
No. 3: ‘Material for ball valve’
VC PVC
No. 4: ‘Material for seal 1’
FP FKM HF
EP EPDM
No. 5: ‘Material for seal 2’
FP FKM HF
EP EPDM
No. 6: ‘Material for valve ball’
KE Ceramic
Suction lance key: Group II
"Technical data" [000|G2|25|2SS|1200]
No. 7: ‘Pressure for valve spring’
000 No spring load
No. 8: ‘Connection thread for lance connector
’
G2 G2''
No. 9: ‘Nominal width of suction pipe
’
25 25 mm (d
i
)
No. 10: ‘Level contacts’
2SS T
wo normally open contacts, cable with plug
No. 11: ‘Suction lance length
’
1200 1200 mm
Technical Data
23 Rev. 1-10.2021
