© 2015 Ecolink Intelligent Technology Inc. PN PIR-ZWAVE2 R1.04
Installation
The package contains the following:
1x Sensor
1x Sensor mounting bracket
4x screws
2x jumper
1x battery
3x pieces of adhesive tape
STEP ONE Mount bracket to wall
First attach the sensor mounting bracket to the wall using either adhesive tape OR screws (optional). For best performance mount the bracket
6.5 to 7.5 feet above the floor (2 to 2.3 meters).
Corner Mount Flush Mount
Adhesive
Bracket
Screws
(Optional)
