Ecolink Z-Wave TBZ500 User Manual

Z-Wave Configurations
There are configuration parameters accessible via the COMMAND_CLASS_CONFIGURATION.
Note all temperature related parameters are in degrees F.
Config
Parameter
#
Description
Length
(bytes)
Send
Unsolicited
on change
Default
Value
Read values
Write values
1
System Type 4
1
N
0
0 = Standard 1 = Heat Pump
0 = Standard 1 = Heat Pump
2
Fan Type 4
1
N
0
0 = Gas (No fan w/Heat) 1 =
Electric (Fan w/Heat)
0 = Gas (No fan w/Heat), 1 =
Electric (Fan w/Heat)
3
Change Over Type 4
1
N
0
0 = CO w/cool 1 = CO w/heat
0 = CO w/cool 1 = CO w/heat
4
2nd Stage Heat Enable 4
1
N
0
0 = Disabled
1 = Enabled
0 = Disabled
1 = Enabled
5
Aux Heat Enable 4
1
N
1
0 = Disabled
1 = Enabled
0 = Disabled
1 = Enabled
6
2nd Stage Cool Enable 4
1
N
0
0 = Disabled
1 = Enabled
0 = Disabled
1 = Enabled
7
C/F Type
1
N
1
0 = Centigrade
1 = Fahrenheit
0 = Centigrade
1 = Fahrenheit
8
MOT 5
1
N
5
5-9
5-9
9
MRT 5
1
N
3
3-9
3-9
10
Setpoint H/C Delta
1
N
3
3-15
3-15
11
H Delta Stage 1 ON
1
N
1
1-6
1-6
12
H Delta Stage 1 OFF
1
N
0
0-5
0-5
13
H Delta Stage 2 ON
1
N
2
2-7
2-7
14
H Delta Stage 2 OFF
1
N
0
0-6
0-6
15
H Delta Aux ON
1
N
3
3-8
3-8
16
H Delta Aux OFF
1
N
0
0-7
0-7
17
C Delta Stage 1 ON
1
N
1
1-6
1-6
