Fig.11bUniversalFilmDispenser.
1‐AdjustmentScrew;2‐TensioningRoller
Switchingto20”Film
Tobeabletouse20”film,loosenthechainonthewallofthe
rotangframeusingthetensioner(on thesideofthechain
drive).Takethechainofthemainspurgearonthemainroller
andnextchangethespur
(Fig.11c)forasmallerone,whichis
situatedonthemainframe(Fig.11d),whichisprovidedwith
themachine.Shortenthechain.Installthegearandtensionit
withtensioners(Fig.5).
Fig.11cSpurGearReplacement.
1‐SpurGearZ‐19;2‐5/8”Chain
Fig.11dPosionoftheAddionalSpurGearforWrappingwith20”
Film.
Fig.11eChainTensioners.
LoadingBalesOntoWrapper&Wrapping
Balesshouldbeloadedontothewrapperusingavailableload‐
ingequipment(theliingcapacityofthedevicesusedmustbe
greaterthantheweightofthebalesbeingwrappedwitha
possibilityofliingthemataheightof40”).Bales
shouldbe
wrappedat their storage locaƟon toavoiddamagingthefilm
duringtheirtransporttoanotherlocaon.Balesshouldbe
loadedfromtheright(withtherotangframewithrollerspo‐
sionedalongthetractor‐wrapperaxis)throughthelightroller
‐thisensuresthebestloading,freeunloading
andefficientfilm
cung.Atthebeginningofthewrappingprocess,thefilm
shouldbepulledfromthedispensermanuallyanditsend
shouldbeaachedtothebalestring,andthehydraulicdrive
totherotangframeshouldthenbeturnedon.
1
2
IMPORTANT!
Fromthefactory ,theEW-450SBale
Wrapperisconfiguredforusewith30”
Film.
