ANALOG OUTPUT TEST
Sends a 0.1 Hz sawtooth waveform to the selected analog output device to test its
functionality. There are 6 analog outputs to choose from (#1 to #6). Analog outputs
#1 to #3 are available via the 50 PIN IO connector.
2.5.12 Calculation factors
CALCULATION FACTORS
INSTRUMENT GAIN : 1.0592
P/T/F CORRECTION : 1.0390
BACKGROUND : 0.0012
ZERO OFFSET : 0.0000 PPB
EXIT
Figure 2-19. Calculation Factors Menu
The Calculation factors screen is a non editable screen which provides the values
used to calculate different aspects of measurement and calibration.
2.5.13 Interface Menu
INTERFACE MENU
ANALOG OUTPUT MENU
DATA LOGGING MENU
MAIN GAS ID : 030
INTERFACE MODE : COMMAND
MULTIDROP BAUD : 2400
DATA LENGTH : 8 BITS
STOP BITS : 1 BIT
PARITY : NONE
COMM. PROTOCOL : ORIGINAL
Figure 2-20. Interface Menu
The INTERFACE MENU is used for adjustments related to the interfacing
instruments.
The following are used only when one or more of the serial ports are to be used.
See output connections information in Chapter 4, Digital Communication.
MAIN GAS ID
The ID address of the analyzer when Multidrop RS232 communications is used.
