UAV engine EFI installation manual-DLE120-V1.4
Copy right ECOTRONS LLC http://www.ecotrons.com
Chapter 3 Broadcast protocol
3.1 ECU broadcast data list on RS232
You can read some parameters of engine from the RS232 serial cable by using your
equipment.
So we provide the protocol to you for using this function.
Variables: RPM, MAP, TPS, ECT, IAT, O2S, SPARK, FUELPW1, FUELPW1, UbAdc.
Note: Enable the broadcast data function; please tune the CV_APP to be 128, then
burn to ECU.
Calibration: CV_APP=128
If you don’t have this variable, please connect us.
The data format is hex, the baud rate is 115200, no parity bit, 8 data bits, 1 stop bit, time
interval 100ms.
Please go to our website to download the document:
http://www.ecotrons.com/support/
Download the Ecotrons Broadcast data list.
See the mark of the Ecotrons Broadcast data list as shown below.
